• Raw Material (Steel Coil)
  • Slitting
  • Uncoiler
  • Tube Rolling
  • Tube Cutting

Main Equipment

MS TUBE 0.5 - 4.5 mm OD 12.7 - 101.6 mm x 1 line ( Kusakabe )
0.5 – 2 mm OD 8.0 - 70.0 mm x 1 line ( Kusakabe )
SS TUBE 0.7 - 2.5 mm OD 19.0 - 63.5 mm x 1 line (New from Saneki - UEX, Japan)
0.7 - 2.5 mm OD 12.7 - 63.5 mm x 1 line (Tig-welding line)
CDW 0.8 - 4.5 mm OD 8.0 – 101.6 mm x 3 line
Slitter 0.27 - 5.0 mm x 1,600 mm x 1 line
0.30 - 3.0 mm x 1,600 mm x 1 line
CTL 0.50 - 3.0 mm x 1,600 mm x 1 line
0.50 - 2.0 mm x 1250 mm x 1 line
0.30 - 3.2 mm x 1600 mm x 1 line (New imported machine)
MINICTL 0.30 - 3.00 mm x 585 mm x 1 line
1.00 - 5.00 mm x 575 mm x 1 line

Stainless Steel Tube Mill

  • Specification of Material: SUS 300 and 400 series JIS G 4307 or equivalent
  • Mill speed: 10 ~ 60 m/min
  • Tube O.D.: 19.0mm ~ 60.5mm
  • Thickness: 1.0mm ~ 2.0mm
  • Length: 4000 ~ 6000 mm
  • Pipe standards: JIS G 3446 & JIS G 3459 and equivalent

Slitting Line

  • Slitting Line
  • Material: CR/SS/GI/GA/AL/PCM
  • Width: Upto 1600mm
  • Thickness: 0.3-3mm
  • Max speed: 60 m/min



CTL Line

Specifications:
Material: CR/SS/GI/GA/AL/PCM
Width: Up to 1650 mm
Thickness: 0.3 mm to 3 mm
Coil capacity: 20 tons
Leveler: 6 Hi leveler
Diagonal tolerance: +/- 0.5 mm
Line Speed: max 60 M/min

Equipment list:
Paper winder, coil car, servo feeder, de-coiler, shearing machine, leveler
Automatic stacker with table


Tube Components Manufacturing

  • SPM machines for pipe complete exhaust line
  • 30 power presses (10-100 Tons)
  • 2 triple-axis CNC bending machine (OD Range: 20-65mm)
  • 5 welding stations
  • New equipment to be added as per growing business
